Weighing PCB / 7135

Micro Controller 89C52
ADC 7135
Internal Counts 4 ½ Digit. 40,000 (-20,000 TO +20,000)
External Counts < 30,000
Sampling Rate ‘3’ Samples per second.
EEPROM 93C46
Display Encoded – 6 digits 7 Segments – LED.
Amplifier Stage 3
Specification :-

Normal Weighing (Power Up Zero).

Hopper / Tank Weighing (Power Up Actual Weight Display)

Peak / Hold Indication.

Weigh Bridge Indicator

Lit / Kg Facility

Single Display Piece Counting.

Level Controller (Up to 5 level)

Filling Controller (Fine / Coarse / Tolerance Adjustment)

Batching Controller (Multiple Ingredients)

Thermal Printer Interface.

LCD / Real Time Clock / VFD … Interface Options.

RS232 Computer Interface / RS 485 Interface.

PLC Compatible 0-10VDC or 4-20mA Current O/p.
