The 65058 is a mid to high capacity, nickel plated alloy steel, double ended Shear beam load cell. This product is designed for use in certified truck and rail scales and is available in capacities ranging from 10K to 200Klbs. This load cell is rated intrinsically safe by the Factory Mutual System (FM); making it suitable for use in potentially explosive environment. This load cell is certified for legal for trade applications by both American NTEP and International OIML standards.
As a renowed and leading sensortronics Load Cell distributor, Dealer, supplier and exporter in India we have supply and exported sensortronics Load Cell in various cities and states of India such as, Mumbai, Pune, Nagpur, Gujarat, Hyderabad, Ahmedabad, Vadodara, Surat, New Delhi, Bangalore, Andhra Pradesh, etc. and exporting other countries like Malaysia, China, Korea and Soudi Arabia.
| Red | Excitation + |
| Black | Excitation - |
| Green | Signal + |
| Yellow | Signal - |
| Performance Specification | |
|---|---|
| Standard Capacities | 5,10,15,20,23,30,40,50,75,100 - Tf |
| Excitation Voltage | 10 VDC- Maximum 15 VDC |
| Nominal Output | 3.0 mV/ V |
| Non - Linearity | < ±0.025% FSO |
| Hysteresis | < ±0.02% FSO |
| Non-Repeatability | < ±0.01% FSO |
| Creep (30 minutes) | < ±0.01% FSO |
| Zero Balance | ±1.0% FSO |
| Input Resistance | 770 ± 20 Ohms |
| Output Resistance | 700 ± 7 Ohms |
| Insulation Resistance (50 VDC) | > 1000 Mega Ohms |
| Safe Overload of Rated Capacity | 150% |
| Ultimate Overload of Rated Capacity | 300% |
| Allowable Side Load | 50% |
| Side Load Discrimination | 500:1 |
| Temp. Compensated Range | 0-60 0C |
| Temperature Effect on Output | < 0.0015% FSO/ 0C |
| Temperature Effect on Zero | < 0.0020% FSO/ 0C |
| Deflection | < 0.5 mm at FSO |
| Tightening Torque | 10 m.kg. |
| Finish & Construction | Electroless Nickel Plated Tool Steel |
| Environmental Protection Class | IP68 |
