| Standard Capacities |
100, 200, 400, 500, 700 - Gmf 1,1.5, 2 - Kgf |
| Excitation Voltage |
10 VDC- Maximum 15 VDC |
| Nominal Output |
1.6 mV/ V |
| Non - Linearity |
< ±0.025% FSO |
| Hysteresis |
< ±0.02% FSO |
| Non-Repeatability |
< ±0.01% FSO |
| Creep (30 minutes) |
< ±0.03% FSO |
| Zero Balance |
±5.0% FSO |
| Input Resistance |
420 ± 15 Ohms |
| Output Resistance |
350 ± 3 Ohms |
| Insulation Resistance (50 VDC) |
> 1000 Mega Ohms |
| Cable Length (4 Core Screened) |
300 mm. Minimum |
| Safe Overload of Rated Capacity |
150% |
| Ultimate Overload of Rated Capacity |
200% |
| Temp. Compensated Range |
0-60 0C |
| Platter Size |
120mm dia. |
| Eccentric Load Effect |
< 0.02% of FSO at 1/3 rated load placed within the specified sized platter |
| Deflection |
< 0.5 mm at FSO |
| Finish & Construction |
Aluminium Alloy |
