Model 70310-double ended shear beam Load cell is ideally suited for truck, track, tank and hopper weighing applications. From its nickel exterior protection to its triple-seal gage area, this cell is designed to withstand the rigorous of harsh environmental conditions. The cell is compatible with the "Unlink" suspension system and is a direct replacement for the 65058. THIS cell IS USED WITH THE ADI ARTECH WM-V-WEIGH MOUNT. -at an extra cost.
As a renowed and leading Adi Load Cell 70310 manufacturer, supplier and dealer in India we have supply and manufacture Adi Load Cell 70310 in various cities and states of India such as, Mumbai, Pune, Nagpur, Gujarat, Hyderabad, Ahmedabad, Vadodara, Surat, New Delhi, Bangalore, Andhra Pradesh, etc. and exporting other countries like Malaysia, China, Korea and Soudi Arabia.
| Red | Excitation + |
| Black | Excitation - |
| Green | Signal + |
| Yellow | Signal - |
| Performance Specification | |
|---|---|
| Standard Capacities | 5,10,15,20,23,30,40,50,75,100 - Tf |
| Excitation Voltage | 10 VDC- Maximum 15 VDC |
| Nominal Output | 3.0 mV/ V |
| Non - Linearity | < ±0.025% FSO |
| Hysteresis | < ±0.02% FSO |
| Non-Repeatability | < ±0.01% FSO |
| Creep (30 minutes) | < ±0.03% FSO |
| Zero Balance | ±1.0% FSO |
| Input Resistance | 770 ± 20 Ohms |
| Output Resistance | 700 ± 7 Ohms |
| Insulation Resistance (50 VDC) | > 1000 Mega Ohms |
| Safe Overload of Rated Capacity | 150% |
| Ultimate Overload of Rated Capacity | 300% |
| Allowable Side Load | 50% |
| Side Load Discrimination | 500:1 |
| Temp. Compensated Range | 0-60 0C |
| Temperature Effect on Output | < 0.0015% FSO/ 0C |
| Temperature Effect on Zero | < 0.0020% FSO/ 0C |
| Deflection | < 0.5 mm at FSO |
| Tightening Torque | 10 m.kg. |
| Finish & Construction | Electroless Nickel Plated Tool Steel |
| Environmental Protection Class | IP68 |
