Special Applications / 90610M

Description :-

We are leading Pancake Loadcell Supplier in Mumbai, India. 90610-Mini pancake compression load Cells are suitable for applications where space is constraint. This is constructed from heat treated stainless steel suitable for harsh and hygenic industrial applications. It is sealed for IP-65 protection and it has long life. Extremely suitable for automation,tensile testing and force measurement. 90610-Mini is available with integral load button.

Electrical Termination :-
Red Excitation +
Black Excitation -
Green Signal +
Yellow Signal -
Features :-

50 Kgf to 500 Kgf Capacities.

Complete environmental protection - IP65 class.

Standard output 2.0 m V/V available. Hardened stainless steel construction.

Miniature and low profile.

Easy for installation.

Custom built design available on request.

Available with mounting threads optionally.

Applications :-

Tensile testing.

Force and impact test.


Test Bench.


Industrial Force Measurement.

Performance Specification
Standard Capacities 50,100,200,500 KGF.
Excitation Voltage 10VDC-Maximum 15VDC
Nominal Output 2.0 mV/V
Non - Linearity <±0.1% FSO
